Decimator DMON-6S – 6 Channel Multi-Viewer
ENQUIRE NOW1 to 6 Channel MultiViewer with SDI and HDMI outputs for 3G/HD/SD and Custom Layouts
• Low cost miniature (3G/HD/SD)-SDI 1 to 6 channel Multi-Viewer or 6 to 1 input multiplexer
• 6 x (3G/HD/SD)-SDI active loop copies of each input
• Custom Layouts with various standard layouts
• 16 Character UMD overlay per window with individual enables, custom positioning and size
• 16 Channel Audio Metering overlay per window with individual enables, custom positioning and size
• Safe Action and Safe Title overlay per window with individual enables and adjustment
• Centre Cross overlay per window with individual enable
• Audio ID overlay
• Tallies can be applied to either Tally Boxes (Default), Outside Safe Action Area or Border
• Tally boxes allows for up to 4 Tallies per window (Green, Red, Blue and Yellow)
• Load and restore Custom Layouts
• Fast switching between inputs using Full-Screen scaling
• Selectable output format in both Full-Screen and Multi-Viewer mode
• Low latency buffering for each input allowing non-synchronous inputs
• Linked (3G/HD/SD)-SDI and HDMI outputs
• 6 x (3G/HD/SD)-SDI inputs with auto detection (6 Formats supported in total)
• Each window is independent of the others, allowing any 3G/HD/SD format of any frame rate to be displayed simultaneously
• Variable aspect ratios per window
• Pass-Through mode allowing any of the 6 inputs to be selected and routed to both the (3G/HD/SD)-SDI and HDMI outputs
• The DMON-6S is a truly portable converter, that incorporates our new easy to use LCD and button control system. This gives you easy access to most of the amazing features without using complicated LED/button control, dip switches or having to carry around a computer to change a simple setting.
SDI INPUT & OUTPUT FORMATS
3G: SMPTE 424M@2.97 and 2.967Gb/s
1080p@60/59.94/50Hz
HD: SMPTE 292M/274M/296M@1.485 and 1.435Gb/s
1080i@60/59.94/50Hz
1080p/psf@30/29.97/25/24/23.98Hz
720p@60/59.94/50/30/29.97/25/24/23.98Hz
SD: SMPTE 259M@270Mb/s
625i50
525i59.94
HDMI OUTPUT FORMATS 1080p@60/59.94/50Hz
1080i@60/59.94/50Hz
1080p@30/29.97/25/24/23.98Hz
720p@60/59.94/50/30/29.97/25
625i50 / 525i59.94
LED STATUS Power
6 x Signal lock and rate
POWER +5V to +32V DC
Positive Centre Pin
LCD / BUTTON MENU OPTIONS HDMI output type
Output Select
Multi-Viewer Output Format
Multi-Viewer Number of Windows
Multi-Viewer Layout
Multi-Viewer Audio Source
Multi-Viewer Reference
Full Screen is Scaled
Input Routing
GPI mode
Setup
INPUTS 6 x (3G/HD/SD)-SDI
Input Equalization > 100M using Belden 1694A
USB for control and updates
OUTPUTS 6 x SDI (3G/HD/SD)-SDI Active Loop-throughs
2 x SDI (3G/HD/SD)-SDI
HDMI Type A
DIMENSIONS 220mm x 103.7mm x 29.5mm (8.7” x 4.1” x 1.2”)
