Sony PVM-741 OLED 8″ Monitor

ENQUIRE NOW

The PVM-741 is a high-performance, 7.4-inch (188-mm)* OLED (organic light-emitting diode) monitor backed by TRIMASTER ELâ„¢ technology. By optimally combining Sony’s OLED display panel technology with a 10-bit panel driver and Sony’s processing technology, the PVM-741 monitor achieves superb picture quality – unparalleled black performance, a wide colour gamut, and quick pixel response with virtually no motion blur.

In addition to this picture performance, the PVM-741 monitor’s hallmarks are its mobility and the smart and convenient features required for a small monitor – it has evolved in a steady, balanced way. The PVM-741 is ideal for a wide range of professional monitoring applications, including use in an studio camera monitoring, outside broadcast, on set acquisition for digital cinema, field production, editing studio and even research and development.

  • 1 x IEC 13A Power Cable
  • 5m BNC Cable
  • Peli Case

PanelOLED panel
Picture Size (Diagonal)188.0 mm
7 1/2 inches
Effective Picture Size (H x V)163.9 x 92.2 mm
6 1/2 x 3 5/8 inches
Resolution (H x V)960 x 540 pixels (Quater HD)
Aspect16:9
Pixel Efficiency0.9999
Panel DriveRGB 10-bit
Viewing Angle (Panel Specification)89°/89°/89°/89° (typical) (up/down/left/right contrast 10:1)
Normal Scan0% scan
Over Scan5% over scan
Colour TemperatureD65, D93, UserComposite InputBNC (x1), 1.0 Vp-p ±3dB sync negative
SDI InputBNC (x2)
HDMI InputHDMI (x1) (HDCP correspondence)
Audio InputStereo mini jack (x1), -5 dBu 47 kΩ or higher
Parallel RemoteModular connector 8-pin (x1)
(Pin-assignable)
Serial Remote (LAN)RJ-45 (x1) (Ethernet, 10BASE-T/100BASE-TX)
DC InputXLR-type 4-pin (male) (x1), 12V DC (output impedance 0.05 Ω or less)Composite OutputBNC (x1)
Loop-through, with 75 Ω automatic termination
SDI OutputBNC (x1)
Output signal amplitude: 800 mVp-p ±10%
Output impedance: 75 Ω unbalanced
Audio Monitor OutputStereo mini jack (x1)
Speaker (Built-in) Output0.5 W (mono)
Headphone OutputStereo mini jack (x1)Power Requirements100 V to 240 V AC, 0.5 A to 0.3 A, 50/60 Hz
12 V DC, 1.9 A
Power ConsumptionApprox. 30 W (max.)
Inrush Current(1) Maximum possible inrush current at initial switch-on (Voltage changes caused by manual switching): 51 A peak, 7 A r.m.s. (240V AC)
(2) Inrush current after a mains interruption of five seconds (Voltage changes caused at zerocrossing): 17 A peak, 2 A r.m.s. (240V AC)
Operating Temperature0°C to 40°C (Recommended: 20°C to 30°C)
32°F to 104°F (Recommended: 68°F to 86°F)
Operating Humidity30% to 85% (no condensation)
Storage/Transport Temperature-20°C to +60°C
-4°F to +140°F
Storage/Transport Humidity0% to 90%
Operating/Storage/Transport Pressure700 hPa to 1060 hPa
